Popular Laser Choice Product provide 3d laser,laser flashlight,laser led,laser meter,laser pointer Fast Limited 20Kpps laser scanning galvo scanner ILDA Closed Loop max 30kpps for laser 3D Printer. Price at this time US $84.98/piece. Check price now to get discount! Dont waste your time. Buy Now only in stage-lighting-store Trusted Seller Store!
Affordable rate and also cost-free shipping. Allow's buy prior to rates rise.
This Discount Fast Limited 20Kpps laser scanning galvo scanner ILDA Closed Loop max 30kpps for laser 3D Printer item is very special, made with top quality materials definitely resilient for usage in a long duration. Prior to you use it, ensure you check out the guide thoroughly. Do not slip up when utilizing it. Quality items guarantee your life extra comfy when using it. You could straight speak to the sales to obtain more information about this top quality goods if you are interested to get it.
20Kpps laser galvo sets scanner ILDA Closed Loop max 30kpps for Stage Laser 3D Printer
Product Description :
Standard package includes(same as the picture showing) :
- 2×Scanners
- 1x main board (show card)
- 2×Driver board
- 2×Mirrors
- 1×Scanner mount
- 1×power supply (PUS)
- 2×Cables driver to scanner
- 2×Cables driver to PUS
- 2×Cables driver to input signals
- 2x DB25 connector
- 1x microphone connector
- 1x dipswitch
- 1×User manual
SPECIFICATION:
- Closed Loop Moving Magnet Scanner
- Input resistance: 200K ohms, differential
- Signal Input voltage:±5V
- Input voltage requirements: +15V/1.0A,-15V/0.6A
- Operating temperature range:0~50 degrees C
- Optical angle:±30° max
- Scanner speed:>15Kpps (30K ILDA test-pattern ,±20°optical)
- Mirror dimensions WxL: 7mm*11mm*0.6mm(wide wave-length)
- Board size:7.4cm (long) * 5.0cm (wide) * 2.5cm (high)
The Scanner was measured by an independent source and confirmed by the factory
with PANGOLIN QM2000 card.Running at the desired output speed. Using the standard
ILDA test pattern. Laboratory power supply at +/-15VDC,room temperature. Windows
PC with Pangolin,12/30k ILDA test-frame full size. 7x11x0.6mm mirror was used during
measuring period. The galvo is fixed in the standard mounts on an aluminium base plate,
no forced cooling.
Deflection angle | Operating voltage | Speed@ Mirrors size |
20º optical deflection | +/-15V | 18Kpps @ 7*11*0.6 |
15º optical deflection | +/-15V | 25Kpps @ 7*11*0.6 |
5º optical deflection | +/-15V | 30Kpps @ 7*11*0.6 |
Power input | |||
XH-3 Connector pins | Description | Remark | Cable color |
3 | +VCC | +15V/1.0A | RED,24AWG |
2 | GND | BLACK,24AWG | |
1 | -VEE | -15V/0.6A | WHITE,24AWG |
Signal Input | |||
3 | Control signal Y+ | -5V~+10V analog signal | |
2 | S-GND | Ground | |
1 | Control signal - | -5V~+10V analog signal | |
- IS Input scale (adjusted only in factory)
- SG Servo gain (power of the feedback signal for internal PID controller
- LFD Low frequency damping (correct overshoot)
- HFD High frequency damping (correct undershoot)
- LIN Zero offset (electrical offset of the driver, adjusted only in factory)
- PS Position scale (increases or decrease input sensitivity of the computer, DO NOT change it)
