laser engraving mechanical arm
| Parameters | |
| Number of axles | 4 |
| Payload | 500g |
| Maximum stretch distance | 320mm |
| Repeatability precision | 0.2mm |
| CI | USB(USB-to-UART)/ WIFI/ Bluetooth |
| Supply Voltage | 100V-240V, 50/ 60 Hz |
| Power input | 12V / 7A DC |
| Power | 60W Max |
| Working TEMP | -10℃-60℃ |
| Axis motion parameter | ||
| Axis | Working range | Maximum speed (work load 200g) |
| Axis 1 base | -135°to +135° | 320°/ s |
| Axis 2 big arm | 0°to +85° | 320°/ s |
| Axis 3 small arm | -10°to +95° | 320°/ s |
| Axis 4 rotation | +90°to -90 | 480°/ s |
| Physical characteristics | |
| Weight | 4KG |
| Base size | 158mm*158mm |
| Material | Aluminum Alloy 6061, ABS Engineering Plastic |
| Control box | Dobot Integrated Controller |
| Rotbot Installation | Desktop |
| Packing specification (L * w * h) | 330mm*224mm*307mm |
| Software applications | |
| Software | DobotStudio, Repetier Host GrblaController3.6, Graphic Programing |
| SDK(software development kit) | Communication protocol, Dobot Library |
| Extended I/O interface | 1.I/O*10 (for analog signal input or pulse output) |
| 2.Controllable 12V voltage output port *4 | |
| 3.CI（UART, Reset 12V.3.3V and two I/O included） | |
| 4.Extended stepper motor interface *2 | |
| End-of-arm tooling | ||
| 3D printing | Size(L*W*H) | 150MM*150MM*150MM |
| Material | PLA | |
| Resolution | 0.1MM | |
| Laser | Power Consumption | 500mw |
| Type | 405nm(Blue laser) | |
| Power | 12V, TTL trigger | |
| Pen holder | Pen Diameter | 10mm |
| Sucker | Sucker Diameter | 20mm |
| Pressure | -35Kpa | |
| Claw | Range | 40mm |
| Drive mode | Air-operated | |
| Gripping ability | 8N | |
